Truck Beds Info
SD-Service Deck Bed
Our Service Bed offers multiple tool boxes and options for your on the go needs.
ST-Skirted Bed
Two standard toolboxes and the ability to add two more give this bed additional utility.
SF-Smooth Rails
The SF model is a real workhorse with smooth outer side rails and concealed stake pockets.
SR-Diamond Plate
Full tread-plate construction with rub rail and stake pockets for endless tie down options.
WH-Western Hauler
This bed is the perfect companion to your tricked out stock rig.
SC-Service Body Bed
For the Tradesman - This bed can store all your jobs site tools and parts.
Length: Measurement from cab to end of frame.
Width: Measurement from outside of tire to outside of tire
CTA: Measurement from cab to axle
Runner: Measurement from outside of frame to outside of frame at the rear of the frame.
Models: ST, SF, SR, SD
Order Method: Model x Length x Width x CTA x Runner
Example: ST 9’4”L x 97”W x 60”CTA x 34” Runners (Add options) Note: 11’ long beds will have 84” CTA
Ford: 1998-Present
Dually – 8’6”L x 97”W x 56” CTA x 38” Runners
Single Wheel Long Wheel Base – 8’6”L x 84”W x 56”CTA x 38” Runner
Single Wheel Short Wheel Base – 84”L x 84”W x 40”CTA x 38” Runner
Cab & Chassis – 9’4”L x 92”W x 60”CTA x 34” Runners
F-350 takes a 92”W
F-450 & 550 are 94” & 97”W with Standard Headache Rack
2015 F650 Runners 34.5”
GM / Chevrolet: 2001-Present
Dually – 8’6”L x 97”W x 56”CTA x 42” Runners
Single Wheel Long Wheel Base – 8’6”L x 84”W x 56”CTA x 42” Runner
Single Wheel Short Wheel Base – 84”L x 84”W x 42”CTA x 42” Runner
Cab & Chassis – 9’ 4”L x 90” or 92”W x 60”CTA x 34” Runners
(Prior to 2000 measurements will be required)
4500 & 5500 is 94”W with 60” Headache Rack
Dodge: 2003-Present
2007 Cab and Chassis – 9’4”L x 94”W x 60”CTA x 34” Runner
Mega Cab – 84”L x 97”W x 40” CTA x 42” Runners
Mega Cab – 84”L x 84”W x 38” CTA x 42” Runners
Dually – 8’6”L x 97”W x 58”CTA x 42” Runners
Single Wheel Long Wheel Base – 8’6”L x 84”W x 58”CTA x 42” Runner
Single Wheel Short Wheel Base – 84”L x 84”W x 38”CTA x 42” Runner
2002 and earlier will have 56” CTA and 38” Runners on long bed
